CapnoFlex LF CO
2
Refer to Operators Manual for Any Specific Questions.
For Customer Support or Clinical Helpline,
Call: 1-800-558-7044.
!
CapnoFlex LF CO
2
is a continuous, non-invasive technique for determining
the concentration of carbon dioxide (CO
2
) in respiratory gas.
CapnoFlex LF CO
2
Setup Procedure
Caution: Do not use this module on patients that cannot tolerate the removal of
50ml / 1 min from their total minute ventilation.
1. Plug the module into the CO
2
connector (yellow port)
on the Dash monitor
■
The CO
2
parameter window will automatically display once the
module is connected.
■
The message “WARMING UP” will be displayed for approximately
two minutes after the module has been connected.
CapnoFlex LF CO
2
Module Connection to Dash Monitor
CO
2
Parameter Window with Warming Up Message
