SETUP
© 2017 General Electric Company – All Rights Reserved. ADTS 405 R/F Mk2 Instruction Manual-English | 85
7.3.6 SETUP, [MORE], [DISPLAYS/OPTIONS], [DISPLAY TYPE]
The display can be configured for SINGLE, DUAL or TRIPLE displays. The key press sequence
changes the display parameters, the 2nd key press column shows the parameter that
changes on entry of a numeric value.
The tables show all available parameter combinations with an associated key press
sequence.
Table 7-3: Aeronautical Units Dual Display
1
st
Key Press 2
nd
Key Press Upper Display Lower Display
ALT SPEED ALT CAS or TAS
ALT MACH ALT MACH
Any key ROC ALT ROC
SPEED RATE CAS or TAS RATE CAS
MACH
a
a. The Mach parameter changes on numeric entry.
RATE MACH RATE MACH
SPEED MACH MACH CAS/TAS
SPEED ALT ALT SPEED
MACH ALT ALT MACH
MACH SPEED MACH SPEED
Table 7-4: Pressure Units Dual Display
1
st
Key Press 2
nd
Key Press Upper Display Lower Display
Ps Qc Ps Qc
Ps Pt Ps Pt
Ps EPR Ps EPR
Any key RATE Ps Ps RATE Ps
Qc RATE Qc RATE Qc
Pt RATE Pt RATE Pt
EPR RATE EPR RATE EPR
Pt Qc Pt Qc
Qc Ps Ps Qc
Pt Ps Ps Pt
EPR Ps Ps EPR
Qc Pt Pt Qc
