Power Supply
© 2017 General Electric Company – All Rights Reserved. ADTS 405 R/F Mk2 Instruction Manual-English | 9
2.3 Power Supply
See Safety and Installation Guide 124M8686 for full details.
2.3.1 AC Input
2.3.2 DC Input (Option ADTS 405F Mk2 Only)
2.3.3 ADTS 405R Mk2 Rack-mounted Version
1. The unit must be connected to the correct electrical power supply as stated, beside
the power connectors on the rear panel.
2. Install an easily accessible isolator in the power supply circuit.
10a AA500F-19 Red Hose (State Length in Metres)
ADTS 405F/R
10b AA500F-20 Blue Hose (State Length in Metres)
10c AS405-53-1729M0 Yellow Hose, 15 m
ADTS 405R
10d AS405-54-1729M0 Green Hose, 15 m
11 AS405-60-1891M0 Altimeter Encoder Cable ADTS 405F/R
12 AS405-82-1891M0 O-ring Kit ADTS 405F/R
13a AA500F-22 Hose Connector AN4
ADTS 405F/R
13b AA500F-23 Hose Connector AN6
14 AS405-31-1891M0 DC Power Cable ADTS 405F
RISK OF ELECTRIC SHOCK The power supply switch on the front
panel is not classified as a disconnecting device. To isolate the power
supply disconnect the power supply connector.
Table 2-3: AC Power Supply Requirements
Voltage Frequency Power
100/120/230 V 50/60 Hz
500 VA
115 V 400 Hz
INFORMATION A protective earth connection must also be made for
DC operation or specified EMC performance may be impaired.
Table 2-4: DC Power Supply Requirements
Voltage Power
16 to 30 V 500 VA
Table 2-2: Spares and Accessories List
Item Part Number Description Used On
