3. Getting Started
Make sure the electrical and pneumatic connectors, electrical cables, pipes and positioning of
the ADTS 405 Mk2 comply with the instructions in this manual and local regulatory
requirements.
3.1 Preparation
Carry out the following before use:
a. If necessary, carry out the maintenance detailed in Section 5.3, “Maintenance Tasks,”
on page 50.
b. Make sure the air data test system power supply switch on the front panel is set to
OFF.
c. Connect the air data test system to the electrical supply.
d. Inspect the pneumatic hoses for damage, ingress of dirt and moisture. Make sure the
aircraft adapters are serviceable.
3.2 Start-up
3.2.1 Connections
a. Connect the hoses for the test procedures to the air data test system:
i. Red hose to the STATIC output (Ps).
ii. Blue hose to the PITOT output (Pt).
b. Temporarily seal the free ends of the hoses.
Note: When connected take care not to restrict air flow to the hoses.
c. Connect the hand terminal to the air data test system through the hand terminal
connector on the front panel. If necessary, connect the hand terminal through the
extension cable.
WARNING Observe safety precautions stated in local orders and the
aircraft or equipment servicing procedures.
RISK OF ELECTRIC SHOCK The electrical supply must include a
connection to a protective earth. See Safety and Installation Guide
124M8686 for start-up safety checks and information.
INFORMATION Before use, the ADTS 405 Mk2 should be tested. Review
and become familiar with the overall operating states and test procedures
before starting any test process on an aircraft or component.
