Product Views
© 2017 General Electric Company – All Rights Reserved. ADTS 405 R/F Mk2 Instruction Manual-English | 13
Figure 2-5: ADTS 405R Mk2 Front Panel View
1 Cover plate for communications
connectors
2 Altitude sensor datum height (altitude
reference level)
3 Solenoid valve status indicator 4 System status indicator
5 Hand terminal connector 6 Altitude encoder connector (optional)
7 Static output connector 8 Keypad and display
9 Pitot output connector 10 Power connection indicators
11 Power supply switch 12 Calibration enable switch
1
2
3
4
5
6
7
8
9
10
11
12
