– 13 –
5
Remove and swap the 2 cover caps and door handle
from the outer door:
A. Squeeze the tabs on the inside of the door handle
clips. Push clips through the outer door.
B. Squeeze the tabs on the inside of the cover caps. Push
caps through the outer door.
C. Push the door handle clips into the openings on the
opposite side of the outer door making sure you flip
the handle so it curves to the inside.
D. Push the cover caps into the openings on the outer
door where the handle used to be installed.
Door handle
Door handle
Door handle clip
Door handle clip
Cover cap
Inside of door
Inside of door
Cover cap
6
With the cover caps and door handle in place, mount the
inner door back into the outer door with the screws
removed in step 4. Make sure you mount the hinges on
the side opposite the handle.
7
Mount the assembled door on the 2 upper left side hinge
screws installed in step 2. Move the hinge screws
loosened in step 3 into the lower left side screw holes.
Tighten those screws enough to hold the door but still
allow a slight adjustment. Close the door. Adjust the door
so there is equal gap on all sides. Carefully open the door
and firmly tighten all 4 screws.
8
Install the 4 plastic caps removed in step 1 into the 4
right side front panel holes.
NOTE: To return the door to the original setup, follow these
instructions, swapping “left” and “right”.
When you finish
Plug the dryer back into its electrical outlet.
Hang door and
tighten screws
Door
Edge
screws
Door
hinge
screws
Inside screws
Inside screws
Handle
