– 12 –
Reversing the Door Swing
Note: These instructions are for changing the dryer so the door
opens from the right side.
Tools needed:
Standard #2 Phillips screwdriver
Tape-tipped putty knife
Small flat blade screwdriver
Before you Start
Unplug the dryer from its electrical outlet.
1
Open the door approximately 170 degrees. With a putty
knife, remove the 4 plastic covers located along the left
side of the front panel and set them aside.
2
Remove the bottom screw from each hinge (right side)
and partially insert them into the top left side hinge
holes.
NOTE: All 4 front panel hinge screws will now be in the top
hinge holes - 2 on the left and 2 on the right.
Plastic Cover (4)
Left side of
front panel
3
Loosen the bottom 2 right side hinge screws. Remove the
door and place it on a protected, flat surface to avoid
any damage. Remove both the Blind Plate and the Strike
Plate and install them in opposite positions.
4
Remove the 4 door hinge screws, 4 edge screws, and 8
inside screws. Lift the inner door upwards using a flat
blade screwdriver.
Blind plate
Inner door
Strike plate
Door hinge
screws
Inner door
Outer door
Inside screws
Inside screws
Edge
screws
Note: Some doors may have 4 inside screws and 4 additional
edge screws.
(Continued next page)
