GE LOGIQ S8 User Manual

GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
Section 3-10 - Printer Installation 3 - 57
3-10-1-4 BW Printer setup summary
Win* = Windows Printer Setting, L=Landscape/P=Portrait
Util** = LOGIQ Utility Printer Setting, L=Landscape/P=Portrait
Table 3-6 Setup Summary
System Printer Size Win* Util**
Print Size
(approx) Note
R1 UP-D897 960x1280 P P Medium Previous Service Manual recommendation
1920x1280 P P Medium New recommendation
1920x1280 L L Large
UP-D898 N/A N/A N/A N/A R1 uses UP-D897 emulation
R2 UP-D897 960x1280 P P Medium Previous Service Manual recommendation
1920x1280 P P Medium Recommended
1920x1280 L L Large
UP-D898 960x1280 P P Very small Unfit for use
1920x1280 P P Medium Recommended
1920x1280 L L Large
R3 Upgrade UP-D897
UP-D898
960x1280 P P Small or Medium Not recommended on UP-D898
1920x1280 P P Medium Recommended (Monitor size same as R1/R2)
1920x1280 L L Large
R3 UP-D897
UP-D898
960x1280 P P Small or Medium Not recommended on UP-D898
1920x1280 P P Medium Slightly smaller image compared to R1/R2
1920x1280 L L Large Recommended if “Wide” is too small.
R4/R4.2.5x UP-D897
UP-D898
960x1280 P P Small or Medium Not recommended on UP-D898
1920x1280 P P Medium Slightly smaller image compared to R1/R2
1920x1280 L L Large Recommended if “Wide” is too small.

GE LOGIQ S8 Specifications

General

Type	Ultrasound System
Display Type	LCD
3D/4D Imaging	Yes
Connectivity	DICOM, USB, Ethernet
Display Size	19 inches
Transducers	Linear, Convex, Phased Array
Doppler Modes	Color Doppler, Power Doppler, Spectral Doppler
Operating Modes	B-Mode, M-Mode
Applications	Abdominal, Cardiac, Obstetrics, Gynecology, Vascular, Musculoskeletal
Portability	Cart-based
Transducer Ports	4
