DIRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
Section 1-5 - Labels Locations 1 - 23
Section 1-5Labels Locations
1-5-1 The labels on the cover
The LOGIQ S8 comes equipped with product labels and icons.
These labels and icons represent pertinent information regarding the operation of the unit.
NOTE: The rating label is located on the rear of R1/R2/R3 system.
Figure 1-1 Label location - R1/R2/R3 system
LOGIQ S8/LOGIQ E8
LOGIQ S8 Vet
19” Monitor
23”/22” Wide Monitor
