DIRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
Section 1-3 - Important conventions 1 - 11
Follow instruction for use.
Rear of the system
Probe connector
Symbol indicating that the Instructions for Use are supplied in
electronic form.
Rear Panel
“General Warning Sign” Rear of the system
“Warning” - Dangerous voltage” (the lightning flash with arrowhead)
is used to indicate electric shock hazards.
Internal
“Mains OFF” indicates the power off position of the mains power
breaker.
Rear of the system
“Mains ON” indicates the power on position of the mains power
breaker.
Rear of the system
“ON” indicates the power on position of the power button.
CAUTION: This Power button DOES NOT ISOLATE Mains Supply.
R1/R2/R3 Operator
control panel
Stand-by.
The standby symbol (line partially within a broken circle), indicates a
sleep mode or low power state.
Blue: Stand-by or sleep mode
Green: Power on
R4 Operator control
panel
“Protective Earth” indicates the protective earth (grounding) terminal. Internal
Table 1-7 Label Icons(Continued)
Label/Icon Purpose/Meaning Location

GE LOGIQ S8 Specifications

General

Type	Ultrasound System
Display Type	LCD
3D/4D Imaging	Yes
Connectivity	DICOM, USB, Ethernet
Display Size	19 inches
Transducers	Linear, Convex, Phased Array
Doppler Modes	Color Doppler, Power Doppler, Spectral Doppler
Operating Modes	B-Mode, M-Mode
Applications	Abdominal, Cardiac, Obstetrics, Gynecology, Vascular, Musculoskeletal
Portability	Cart-based
Transducer Ports	4
