GE MAC 1600

Maintenance
RemovingtheMainboard
Usethefollowingproceduretoremovethemainboard.
1.DisconnectthesystemfromACpower.
2.Removethepapertrayasdescribedin“ReplacingthePaperTrayAssembly”
onpage64.
3.Removethebatteryasdescribedin“ReplacingtheBattery”onpage64.
4.Removethedisplayasdescribedin“ReplacingtheDisplayAssembly”onpage
71.
5.Removethekeyboardasdescribedin“ReplacingtheKeyboard”onpage67.
6.Removetheinternalmodem(ifthisoptionisinstalled)asdescribedin“Replacing
theInternalModem(Option)”onpage71.
7.Removetherearconnectorpanel.
8.Separatethemiddleplasticandbaseplasticassemblies.
9.Removethepowersupplyasdescribedin“ReplacingthePowerSupply
Assembly”onpage72.
10.IftheKISSoptionisinstalled,removetheKISSpumpasdescribedin“Replacing
theKISSPumpAssembly(Option)”onpage77.
11.Disconnectandremovethefollowingfromthemainboard:
Item
Description
1
KISSpumpharnessconnector(ifthisoptionisinstalled).
2
BothendsofthegrayUSBcable.
3
ThetwoshorterKISSpumpstandoffs(ifthisoptionisinstalled).
4
ThelongerKISSpumpstandoff(ifthisoptionisinstalled).
5
Thepowersupplyconnector.
96MAC™16002028451-183E
