Maintenance
5.Turnthebottomcoveroverandreplaceandtightenthefourscrewssecuring
theprinterdoortothebottomcover,asshowninthefollowingphotograph.
6.Reattachtheprintermoduleassembly.
Seestep1throughstep2in“ReplacingthePrinterModuleAssembly”onpage
95forinstructions.
7.Reattachthechassis.
Seestep1throughstep6in“AttachingtheChassis”onpage85forinstructions.
8.Reattachthetopcoverassembly.
See“ReattachingtheTopCoverAssemblytotheDevice”onpage81for
instructions.
9.Reinsertthebattery.
Seestep6throughstep8in“ReplacingtheBattery”onpage74forinstructions.
10.ContinuewiththeappropriatefunctionalcheckoutprocedureforthisFRU.
See“FunctionalCheckout”onpage129formoreinformation.
PrinterDoorSensor
Thefollowingproceduresdescribehowtoremoveandreplacetheprinterdoorsensor.
RemovingthePrinterDoorSensor
Usethefollowingproceduretoremovetheprinterdoorsensorfromtheprinter
moduleassembly.
1.Beforebeginninganysteps,followtheinstructionsin“PreparingtheSystemfor
FRUReplacement”onpage73.
2.Removetheprintermoduleassembly.
See“RemovingthePrinterModuleAssembly”onpage94forinstructions.
106
MAC™2000ECGAnalysisSystem
2053535-003C

GE MAC 2000 Specifications

General

ECG Type	Resting ECG
Number of Channels	12
Report Format	PDF, XML
Battery Type	Rechargeable lithium-ion
Connectivity	Ethernet
Data Storage	Internal memory
Display	High-resolution color LCD
Power Supply	Universal AC power supply
