5-36 MAC™ 3500 Resting ECG Analysis System Revision L
2021337-036
Maintenance: Functional Checkout Procedures
Tools
1. ECG Simulator
2. Standard hand tools including a #10 and a #6 Torx Driver
3. Current Leakage Tester
4. Anti-static wrist strap
5. Applicable Service and/or Operator Manual
as needed for reference
6. Floppy Diskette or SD Card
Visual Inspection
Inspect the following for excess wear and or any visual signs of damage.
1. Passed check for defective or broken patient cable/leadwires and out of
date
electrodes?
2. Discussed electrode placement, skin prep, and patient relate
d requirements with
ECG Te
ch?
3. Keyboard/LCD passed inspection?
4. AC Power cord passed inspection?
5. Battery (swollen or leaky) passed inspection?
6. Trolley and casters passed inspection?
7. External surfaces passed inspection?
8. FUSE type and rating passed inspection?
Mag Card Reader 1,2,5 9 1,3,9
Treadmill or Ergometer I/F Cable 1,2,5 9 1,3,6
Blood Pressure Monitor 1,2,5 9 1,3
Table 4. Option Repairs (Continued)
FRU / Option
Tools Visual Inspection Checkout Procedure(s)
Table 5. Non-FRU Repairs
Description Tools Visual Inspection Checkout Procedure(s)
No Parts Replaced 1,5 1,2,3,4,5,6,7 1,3,4
*5 through 9
Software Update 1,5,6 N/A 1,2,3,4
*5 through 9
Hardware Upgrade 1,2,4,5 9,10 1,2,3,4,20
*5 through 9
Annual Electrical Safety Checkout 1,2,3,5 7,9,10 20, 1,2,3
