Revision L MAC™ 3500 Resting ECG Analysis System 6-13
2021337-036
Parts Lists: Field Replaceable Units (FRUs)
MAC 3500 KISS Pump Assembly, pn 2022882-002
Table 3. MAC 3500 KISS Pump Assembly, pn 2022882-002
Item Part Number Item Description
1
1
1 Part not available as a stand-alone FRU. This part is only available as part of the entire assembly.
ASSY KISS PUMP
2 * PCB HOLDER PUMP
4 * CABLE STRIP 293 X 4,8 MM
5 BRACKET KISS PUMP MAC3500
(Only available in a FRU kit. See “MAC 3500 KISS
Pump Hardware Kit, pn
2030872-002” on page 6-29)
6 ASSY WIRE SET KISS PUMP MAC3500
(Only available in a FRU kit. See “MAC 3500 KISS
Pump Hardware Kit, pn
2030872-002” on page 6-29)
8 FITTING PNEU 1/8" QUICK MALE
(Only available in a FRU kit. See “MAC 3500 KISS
Pump Hardware Kit, pn
2030872-002” on page 6-29)
9 M3 X 8MM TORX SEMS
(Only available in a FRU kit. See “Ha
rdware Kit for MAC 3500, pn
2030869-001” on page 6-24)
