Revision L MAC™ 3500 Resting ECG Analysis System A-7
2021337-036
Technical Specifications: Barcode Scanner
Barcode Scanner
Item Description
Symbologies Code 39 (extended), PDF-417, Code 128, Data Matrix, Interleaved 2 of 5.
Dimensions:
Width
Length
2.02 in. (51.3 mm)
4.26 in. (108.2 mm)
Illumination LEDs 526 nm visible red LED
Temperature ranges:
Operating
Storage
32°F to +122°F (0°C to 50°C)
-40°F to +158°F (-40°C to +70°C)
Humidity 95%, non-condensing at +50°C (122°F)
Rotational Sensitivity 360 degrees
Min X Dimension 0.17 mm (6.6 mils)
Reading Distance Up to 22.6 cm (8.9 in), assuming a 13 mil barcode element
Ambient Total darkness to 100,000 Lux (sunlight)
Communications RS-232 up to 115.2K baud
Power Supply 5 VDC +/- 5%
Scanning Current 450 mA
Idle Current 50 mA
Agency compliance RoHS and WEEE Compliant
