Revision L MAC™ 3500 Resting ECG Analysis System 6-17
2021337-036
Parts Lists: Field Replaceable Units (FRUs)
Table 5. Thermal Writer Assembly
Item Part Number Item Description
1
1
1 Part not available as a stand-alone FRU. This part is only available as part of the entire assembly.
BASE, WRITER MAC SERIES
2 422396-003 ASSY ROLLER MAC SERIES WRITER
3 * SPACER PAPER MAC SERIES
4 M3 X 8MM TORX SEMS
(Not available as “stand-alone” FRU. See “Hardware Kit for MAC
3500, pn
2030869-001” on
page 6-24)
5 * CLIP, INT. STAR
6 416015-001 SHOCK CYLINDER
7 * COVER AMP CONNECTOR MAC SERIES
8 * CONN VERT MINI-DRAWER 14P
9 * SPRING, CONNECTOR MAC
11 * PIN SHOCK
12 * FSTNR WIRE CLIP
13
2029559-001
2
2 Part Number 422397-001 can be substituted for this part if available.
PRINTHEAD MAC SERIES WRITER
14 * FRAME WRITER
15 * HINGE FRT MAC SERIES
16 * HINGE RR MAC SERIES
17 * WSHR NYLON 6.4 ID
18 * PIN SHOCK UPPER
19 * SPRING CPRSN HEADPIN
20 * WSHR NYLON -PRINTHEAD
21 FSTNR E-RING
(Not available as “stand-alone” FRU. See “Hardware Kit for MAC
3500, pn
2030869-001” on
page 6-24)
22 * PIN PRINTHEAD
23 * STATIC BRUSH 1212
24 * SPRING PRINTHEAD
25 * PRINTHEAD WELDMENT
26 * SCR MACH PNHD M3 X 6 SIMS
27 * CABLE ASSY RBN MOTOR PCB
To Next Page
