a 50 Hz system) and each aggregator can be configured to support a TCP or a UDP connection to a client allowing the UR
to support a total of two TCP connections or two UDP connections or a combination of a TCP and a UDP connection per
aggregator for real-time data reporting. Also note that if hard fiber is used it will have no impact on this specification.
Precise IRIG-B input is vital for correct synchrophasor measurement and reporting. A DC level shift IRIG-B receiver
must be used for the phasor measurement unit to output proper synchrophasor values.
The PMU settings are organized in five logical groups as follows.
PATH: SETTINGS  SYSTEM SETUP  PHASOR MEASUREMENT UNIT  PHASOR MEASUREMENT UNIT 1
 PHASOR MEASUREMENT
 UNIT 1
 PMU 1 BASIC
 CONFIGURATION
See page 5-91.
MESSAGE
 PMU 1
 AGGREGATORS
See page 5-95.
MESSAGE
 PMU 1
 CALIBRATION
See page 5-97.
MESSAGE
 PMU 1
 TRIGGERING
See page 5-98.
MESSAGE
 PMU 1
 RECORDING
See page 5-105.
