– 69 –
IMPORTANT: Do not overtighten or you may bend
the orifi ce hood or needle.
Use a 4.
1
/
2
-in. open-end or adjustable wrench
to turn the orifi ce hood in the L.P. direction,
clockwise about 1
1
⁄
2
turns, until snug.
Screws
Bake
Burner
Baffle
Screws
Air Shutter
Screw
Orifice Fitting
Cover
Air Shutter
NAT. - LP.
AD
TMENT
L.P.
NAT.
Air
Shutter
Nat.
Air Shutter
Screw
L.P.
Orifice
Fitting
Cover
Nat. – L.P.
Adjustment Made
to Orifice Hood
Adjusting the Oven Burners (on gas oven models only)
Caution: The following adjustments must be made
before turning on the gas to the burner. Failure to do
so could result in serious injury due to high fl ames
and toxic fumes.
Bake Burner
Remove the oven door and the oven bottom.1.
Remove the four screws securing the bake 2.
burner baffl e (fl ame spreader).
Remove the bake burner baffl e (fl ame spreader) 3.
and remove the orifi ce fi tting cover.
(Continued next page)
Broil Burner
Use a 1/2-in. open-end or adjustable wrench to 1.
turn the orifi ce hood in the L.P. direction, about 1
1⁄2 turns, until snug
Note: Turn handle of wrench down for L.P. and up
for Natural Gas.
Air Shutter Setting for Bake and Broil Burners
Use a screwdriver to loosen the air shutter 1.
screw.
Note: Adjust at the opening nearest the air shutter
screw.
Adjust the air shutters. The table below gives 2.
the recommended initial air shutter setting. Your
fi nal settings may vary.
Nat.
Apply
wrench
here
L.P.
Turn handle of wrench down
for L.P. and up for Natural Gas.
INITIAL AIR SHUTTER SETTINGS
Gas Supply Location Dim. “A”
L.P. Gas Broil Burner 11/32″
Bake Burner 11/32″
Natural Gas Broil Burner 11/32″
Bake Burner 11/32″
Air Shutter
n
Air Shutter
Adjustment Screw
Dim. “A”
(See Table)
Retighten the air shutter screw.3.
Note: Bake and broil fl ame must be checked
with the door closed to properly check fl ame
characteristics.
To Next Page
