GE SIGNA Voyager - 3 MR System Cable Specifications

3 MR System Cable Specifications
Table 6-7: MR System Cable Information
RUN# FROM TO Length (mm)
Cable
Diame‐
ter
(mm)
Con‐
nector
Size/
Diame‐
ter
(mm)
bend ra‐
dius
(mm)
Number
of con‐
ductors
AWG
Certifica‐
tion
Voltage
Rating
(volts)
Tempera‐
ture Rat‐
ing (Cel‐
sius)
P5001
Harness (P2003, P2004, P2006, P2009, P2010, P2011)
P2003 ISC MAG 17,050 9.6 13.2 14.4 6 NA
OFNR ,
FT4
NA 85
P2004 ISC MAG 17,700 9.6 13.2 14.4 6 NA
OFNR ,
FT4
NA 85
P2006 ISC MAG 17,800 9.6 13.2 14.4 6 NA
OFNR ,
FT4
NA 85
P2009 ISC MAG 16,550 4.4 15.6 25 2 NA NA -55 to 85
P2010 ISC MAG 17,400 4.4 15.6 25 2 NA NA -55 to 85
P2011 ISC MAG 17,150 4.4 15.6 25 2 NA NA -55 to 85
M5004 Harness (M1302, M1303, M3316)
M1302 ISC MAG 15,140 8.382 22.6 88.9 2 20
CL2,
CMG
300 -30 to 75
M1303 ISC MAG 15,550 4.95 14.53 50.8 1 NA
CMR and
FT4
1000dc -40 to 85
M3316 ISC MAG 15,140 10 39.12 NA 15 22 UL2464 300 80
M5003 Harness (2018, 2019, M3532, M3533, M3534)
2018 ISC-DM Body Coil 19,000 5.0 14.5 15.0 19 20# RG58/U DC30V 80
2019 ISC-DM Body Coil 19,000 5.0 14.5 15.0 19 20# RG58/U DC30V 80
M3534 ISC-DM Hybrid 16,000 5.0 14.5 15.0 19 20# RG58/U DC30V 80
M3532 ISC-DM Body Coil 15,000 5.0 14.5 15.0 19 20# RG58/U DC30V 80
M3533 ISC-DM Body Coil 15,000 5.0 14.5 15.0 19 20# RG58/U DC30V 80
M5002 Harness (M3303, M3379)
M3300 ISC MAG 15750 21 66.9 NA 24
12
22
CL2 30 75
M3379 ISC MAG 16,500 8 30.8 NA 9
22
18
UL2464 300 80
M5001 Harness (M3302, M3303, M3360)
M3302 ISC MAG 15,000 13.6 72.77 NA 37 22 CL3 30 75
M3303 ISC MAG 15,000 13.6 72.77 NA 37 22 CL3 30 75
M3360 ISC MAG 15,220
5.7
10.3
53.04 NA
4
14
26
22
UL2464 300 80
M5005 Harness (M3311, M3313, M3315, M3392)
M3311 ISC Table 18,500 10 53.04 NA 18 22 UL2464 300 80
M3315 ISC Table 18,500 7.8 30.8 NA 9 22 CL3 300 75
SIGNA Voyager Pre-Installation
Direction 5680008–1EN, Revision 2
140 3 MR System Cable Specifications
