6. Control Functions and Parameter Settings
6-26
Block-C parameters (Basic function constants) list
ApplicationNo. Parameter Unit Default Min. Max. Function
ST V/f VEC PM
C14 – Meter output gain
0 Output gain for FM 1.00 0.20 2.00
1 Output gain for AM 1.00 0.20 2.00
10V at Max. frequency when this is
set to 1.00.
5V at the rated current when this is
set to 1.00. (Max. 11V)
C15 – Status output detection level
0 Attainment (ATN)
detection width
% 1.0 0.0 20.0 The attained output (ATN) operation
width is set.
1 Current (IDET)
detection level
% 100. 5. 300. The current detection (IDET)
operation level is set.
2 Speed detection
(SPD1) level – 1
% 95.0 1.0 105.0
3 Speed detection
(SPD2) level – 2
% 50.0 1.0 105.0
The speed detection (SPD1, SPD2)
operation level is set.
4 Zero speed detection
(ZSP) level
% 1.00 0.00 50.00 The zero speed detection (ZSP)
operation level is set.
