FunctionPart
Agitator motor speed setpoint (SP), text box for input.1
Process variable (PV) display.2
Agitator motor drive state indicator: Enabled or Disabled.
Note:
If the agitator motor drive is enabled, but the agitator state is shown as
Stopped, the agitator motor drive is defective.
3
Agitator state indicator: Running or Stopped.4
Batch Timer display.5
STOP button.6
START button.7
Toggle button to change the agitator direction to CW or CCW. See Agitation
direction, on page 67 for more information.
8
Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD 101
4 User interface
4.4 Detail screens
4.4.2 Agitator screen
