Equipment: Proximity switches – actuator without T.VIS
Operating voltage [V] 10...65 DC 20...25 AC
Switching distance [mm] 5 5
Max. continuous current
[mA]
>3...<100 >3...<100
Ambient temperature [°C] -25...+80 -25...+80
Protection class IP 67 IP 67
5.3 Resistance of Sealing Materials
The resistance of sealing materials depends on the type and temperature of the
medium conveyed. The exposure time can adversely affect the service life of the
seals. The sealing materials comply with the regulations of FDA 21 CFR
177.2600 or FDA 21 CFR 177.1550.
Resistance:
•
+ = good resistance
•
o = reduced resistance
•
- = no resistance
Sealing resistance table
Sealing material (general operation temperature)
Medium at permissible
operating
temperature
EPDM
-40...+135°C*
(-40...275°F*)
FKM
-10...+200 °C*
(+14...+392°F*)
HNBR
-25...+140 °C*
(-13...+284°F*)
VMQ
-50...+200 °C*
(-58...+392 °F*)
Caustics up to
3%
up to 80 °C
(176°F)
+
o + o
Caustics up to
5%
up to 40 °C
(104°F)
+ o o o
Caustics up to
5%
up to 80 °C
(176°F)
+ – – o
Caustics at more
than 5%
o – – o
Inorganic acids**
up to 3%
up to 80 °C
(176°F)
+ + + o
Inorganic acids**
up to 5%
up to 80 °C
(176°F)
o + o o
Inorganic acids**
up to 5%
up to 100 °C
(212°F)
– + – o
Water up to 80 °C
(176°F)
+ + + +
Water up to 100 °C
(212°F)
+ + + o
Steam up to 135 °C
(275°F)
+ o o o
Steam, approx.
30 min
up to 150 °C
(302°F)
+ o – o
Technical data
Resistance of Sealing Materials
430BAL009990EN_2
24 30.01.2018
