6.7.1 Electrical connection with T.VIS control top
Danger
Live parts
Electrical shock can result in serious personal injury or death.
► Only allow properly qualified staff to carry out work on the electrical
equipment.
► Prior to establishing electrical connections check the maximum
permissible operating voltage.
Explosive gases or dusts
An explosion can result in serious personal injury or death.
► Observe the installation and operating regulations for use in potentially
explosive areas.
Carry out the following steps:
1.
Connect in accordance with the connection diagram and the instructions in
the corresponding operating instructions for control tops T.VIS M-15, A-15 or
T.VIS P-15.
®
Done
Hint!
The proximity switches are factory set. During transport and
installation it can happen that the settings are changed, so that
readjustment may be required (see the Operating Instructions for the
control top).
6.7.2 Adjusting the proximity switch – actuator without T.VIS
Danger
Live parts
Electrical shock can result in serious personal injury or death.
► Only allow properly qualified staff to carry out work on the electrical
equipment.
► Prior to establishing electrical connections check the maximum
permissible operating voltage.
Explosive gases or dusts
An explosion can result in serious personal injury or death.
► Observe the installation and operating regulations for use in potentially
explosive areas.
Carry out the following steps:
1.
Loosen the cap nuts on the proximity switch.
Assembly and installation
Electrical connections
430BAL009990EN_2
30.01.2018 33
