5.6 Lubricants
Lubricants Material no.
Rivolta F.L.G. MD-2 413-071
PARALIQ GTE 703 413-064
Grease BARRIERTA L 55/3
(only for seals VMQ)
413-137
5.7 Weights
TYPE GS
Size
Weight butterfly valve with actuator [kg]
Manual actuator
Pneumatic actuator
without control top
Pneumatic actuator with
T.VIS control top
DN 25, 1" 1.6 5.5 6.7
DN 40, 1.5" 1.7 5.7 6.9
DN 50, 2" 2.2 6.1 7.3
DN 65, 2.5" 2.4 6.7 7.8
DN 80, 3" 3.6 7.5 8.7
DN 100, 4" 4.8 8.7 9.9
DN 125 7.4 11.4 12.5
DN 150 8.8 13.2 14.4
TYPE SS
Size
Weight butterfly valve with actuator [kg]
Manual actuator
Pneumatic actuator
without control top
Pneumatic actuator with
T.VIS control top
DN 15, 0.5" 1.4 5.3 6.5
DN 20, 0.75" 1.4 5.3 6.5
DN 25, 1" 1.4 5.3 6.5
DN 40, 1.5" 1.5 5.5 6.7
DN 50, 2" 1.9 5.8 7.0
DN 65, 2.5" 2.0 6.3 7.5
DN 80, 3.1 7.0 8.2
3" 3.4 7.3 8.5
DN 100, 4" 4.4 8.3 9.5
DN 125 6.2 10.2 11.3
DN 150 7.0 11.4 12.6
TYPE VV
Size
Weight butterfly valve with actuator [kg]
Manual actuator
Pneumatic actuator
without control top
Pneumatic actuator with
T.VIS control top
DN 15, 0.5" 2.5 6.5 7.7
DN 20, 0.75" 2.5 6.5 7.7
DN 25, 1" 2.5 6.5 7.7
Technical data
Lubricants
430BAL009990EN_2
30.01.2018 27
