Geeetech Prusa I3 pro W Building Instruction

12
www.geeetech.com
Shenzhen GETECH CO.,LTD
NO.15 2 M3 square nut
NO.7 5 M3 washer
Step1. Mount the pulley on the motor shaft, one of the screws should be screwed on
the flat side of the shaft. Screw it as tight as possible.
(Note the direction of the pulley as below picture)
Step2. Then screw the motor on the Y motor holder with 3 M3 x 10mm screws and
M3 washers.
