Geeetech Prusa I3 pro W Building Instruction

25
www.geeetech.com
Shenzhen GETECH CO.,LTD
8 Mount the End stop of Y-axis
Picture Part ID Required quantity Required parts
NO.52 1 End stop
NO.20 2 M2.5 x 16 mm screw
NO.9 2 M2.5 Hex nut
NO.6 2 M2.5 washer
Mount the end stop on the rear support plate of Y axis with M2.5 x 16mm screw,
M2.5 washer and M2.5 Hex nut.

Geeetech Prusa I3 pro W Specifications

General

Brand	Geeetech
Model	Prusa I3 pro W
Category	3D Printers
Language	English
