Geeetech Prusa I3 pro W Building Instruction

37
www.geeetech.com
Shenzhen GETECH CO.,LTD
11 Mount the fan
Picture Part ID Required quantity Required parts
NO.49 1 Fan
NO.25 4
M3 x20 mm
screw
NO.10 4 M3 nut
NO.7 4 M3 washer
Fix the fan on the left back side of the frame with 4 M3 x 20 screws, M3 washer and
