23
www.geeetech.com
Shenzhen GETECH CO.,LTD
7 Mount the Y axis belt
Picture Part ID Required quantity Required parts
NO.35 1 Timing Belts
Step1. Insert one end of the belt in the groove bracket. Pay attention to the tooth mesh
of the belt and the groove.
Step2. Thread the other end of the belt though the pulley of the Y motor.
