27
www.geeetech.com
Shenzhen GETECH CO.,LTD
NO.W1-B 1
X-Z frame
(bottom)
NO.W2 1 Left side frame
NO.W3 1 Right side frame
NO.24 6
M3 x 16 mm
screw
NO.15 6 M3 square nut
NO.7 6 M3 washer
Step1. Screw up the X-Z frame (up) and the side panel with M3 x 16mm screws, M3
washer and M3 square nuts.
