Geeetech Prusa I3 pro W Building Instruction

44
www.geeetech.com
Shenzhen GETECH CO.,LTD
NO.58 2 Stepper motor
NO.22 8
M3 x 10mm
screw
NO.7 8 M3 washer
Step1. Thread the wires of the motors through the holes of the main fame. Then put
the motor under the motor base.
Step2. Screw up the motors with 4 M3 x 10mm screws and M3 washer.
