57
www.geeetech.com
Shenzhen GETECH CO.,LTD
Bearing Bracket No.M4 4
Extruder bracket No.M5 1
Linear Bearing
LM8LUU
No.33 2
Belt bracket No.47 1
M3x6mm screw No. 21 8
M4x6mm screw No. 28 2
M3 nut No.10 2
Step1. Fix the 4 Bearing Brackets on the back of the X Carriage loosely with
M3x6mm screws.
