Geeetech Prusa I3 pro W Building Instruction

73
www.geeetech.com
Shenzhen GETECH CO.,LTD
Driven wheel No.40 1
Ball bearing No.41 2
M3 x40mm screw No.27 1
M4 x 25mm screw No.29 1
M4 Lock nut No.13 1
Wing nut No.14 1
Step1. Thread M3 x 40 screw through the driven wheel holder .
Step2. Insert the driver wheel with the ball bearing into the middle of the driving
wheel holder. Put the M4 x25 screw through the driving wheel. Lock the other end
with a M4 lock nut. You may need a pair of pliers to tighten locking nut.
