Geeetech Prusa I3 pro W Building Instruction

84
www.geeetech.com
Shenzhen GETECH CO.,LTD
NO.31 4 Spring
NO.44 4 Dovetail clamp
NO.14 4 Wing nut
NO.56 1 Borosilicate glass
Mount the heat bed on the platform with 4 M3 x35 screws, M3 washers and wing nuts.
Clamp the heat bed and the glass sheet.
*The soldered side is better to be attached downwards.
The order should be:
M3 x35mm screw—washer—Heat bed— Spring—washer—Wood support plate—
washer—Wing nut
