Geeetech Prusa I3 pro W Building Instruction

8
www.geeetech.com
Shenzhen GETECH CO.,LTD
Picture Part ID Required quantity Required parts
NO.3 2 φ8 smooth rod
NO.32 3
LM8UU Linear
bearings
NO.18 2 Screw locking ring
①Take out the 410mm smooth rod
Slide 3 Linear bearings on the smooth rods，one smooth rod with two pieces and
another with one. Before you slide the bearings please make sure they are clean.
② Slide the screw locking ring on the end of the smooth rod.
