24 AGL50-EV
7 - Default lift conguration
Lift commands are part of a dedicated control word. Each command is assigned to a physical digital input terminal. All
the main commands are given from the DI on the standard regulation board (see table 7.1).
Similarly, lift digital outputs are congured to perform the most common functions needed to realize a standard applica-
tion, such as run and brake contactor control logic.
In AGL50-EV drives, commands are always coming from Lift Control Word. It is possible to issue the Run Fwd or Run
Rev commands from keypad, in order to simplify the startup procedure.
Frequency references are coming from the multi-speed selector, which is the required setting for most applications.
However, it is possible to use other sources for the frequency reference, such as analog inputs or Motopotentiometer.
Ramps are initialized to a standard set of jerks and acceleration/deceleration that should meet the requirements of most
low speed applications. It is possible, though not recommended, to disable the S-shape and use linear proles (F.250 =
0). In that case the jerk parameters will have no effect.
7.1 Command Logic
In the standard version, drive commands may come from several different sources (keypad, terminals, serial line etc.).
In the Lift version the parameter dening the source of the commands can only assume the following values:
P.000 Cmd source sel = “[0]CtrlWordOnly”
Command assignment
Drive command Source parameter Deafult setting Possible setting IPA
Setting Terminal
Enable src I.000 [2] DI 1 12 [0] False 100
[1] True
[2] DI 1
[3] DI 2
[4] DI 3
[5] DI 4
[6] DI 5
[7] DI 6
[8] DI 7
[9] DI 8
[10] DI Exp 1
[11] DI Exp 2
[12] DI Exp 3
[13] DI Exp 4
[14] AND 1
[15] AND 2
[16] AND 3
[17] OR 1
[18] OR 2
[19] OR 3
[20] NOT 1
[21] NOT 2
[22] NOT 3
[23] NOT 4
[24] FrqSel match
[25] Short Floor g
[26] Contactor (fw 03-07)
[27] Timer 1 (fw 03-07)
Run Fwd src I.001 [3] DI 2 14 See list of I.000 101
Run Rev src I.002 [4] DI 3 16 See list of I.000 102
Freq Sel 1 src I.003 [5] DI 4 18 See list of I.000 103
Freq Sel 2 src I.004 [6] DI 5 20 See list of I.000 104
Freq Sel 3 src I.005 [7] DI 6 22 See list of I.000 105
Freq Sel 4 src I.006 [0] False See list of I.000 106
Ramp Sel 1 src I.007 [25] Short Floor Flg See list of I.000 107
Ramp Sel 2 src I.008 [0] False See list of I.000 108
Ext fault src I.009 [0] False See list of I.000 109
Src Reset Allarm I.010 [0] Falso See list of I.000 110
Bak pwr act src I.011 [0] False See list of I.000 111
Forced stop src I.012 [0] False See list of I.000 185
Table 7.1 – Command assignment
