AGL50-EV 15
Sizes
Radiator Therm. Res.
( °C/W )
P Cont. serv.
( W )
RF 200 100R 0.75 400
RF 200 68R 0.55 550
RF 400 68R 0.4 750
Optional EMC lters
An external EMI lter can be used to meet the requirements of EN 12015.
Sizes Filter type Code
EN61800-3
(Motor cable length)
2040 EMI-FTF-480-7 S7GHL 5 m
2055 EMI-FTF-480-16 S7GHO 5 m
2075 EMI-FTF-480-16 S7GHO 5 m
4.2 EMC compliant electrical cabinet wiring rules
In a domestic environment, this product may cause radio inference, in which case supplementary mitigation
measures may be required.
Panels and cabinets
Mounting panel and cabinet (including the doors) have to be grounded, with a direct connection to the ground bus, using
strapwire.
Removal of the paint from the support areas
The paint should be removed from the choke, mounting panel and chassis support areas.
The anodized aluminium does not conduct.
Ground terminals of the inverter
The inverters are provided with two ground terminals: one must be connected to the ground bus and the other to the lter.
Ground terminal of the choke
The earth terminal of the choke must be connected to the ground bus.
Shielding of cables for analog signals
Analog signals must be shielded (each signal must be contained in the screen united with the zero volt), the same is true
for the constant references (E.g.. 10V). The shield must be grounded at 360° using the omega connectors available on
the support panel of the regulation board. This is in front of the terminals strip on the bar above the board.
Note!
Cable shields should be grounded at one end only.
Min. distance between signal and power cables
The minimum distance between parallel signals and power cables is 30cm (12 inches). Possible crossings have to be
made at 90°. In case of double cabinets (entry to the insde of the cabinet on both sides with 2 different panels installed)
it is advisable to have all signals cables conveyed into troughs mounted on the inverter side (front) and to pass motor
cables on the other side (back) trough. In case of single cabinets, it is advisable to let the power cable run vertically, while
signal cables run horizontally, keeping the maximum possible distance.
Shielding of the supply for an AC motor
The AC motors have to be supplied through a four pole shielded cable (three phases plus a green/yellow ground wire),
or through four unshielded cables, which are inserted inside a metal channel. It is important that a direct connection (four
cables) between the panel grounding and the motor ground has been made and that the fourth cable had been inserted
in a shield.
