ADL300 • Quick installation guide - Specifications and connection 105
SEQ
08 PAR: 11042
Acceleration
0.6 m/s²
Def: 0.6
E
SEQ
08 PAR: 11042
Acceleration
00000000.6 m/s²
Def: 0.6
▲
0.7 m/s²
▼
0.5 m/s²
E
SEQ
09 PAR: 11044
Acc nal jerk
1.4 m/s³
Def: 1.4
E
SEQ
09 PAR: 11044
Acc nal jerk
00000001.4 m/s³
Def: 1.4
▲
1.5 m/s³
▼
1.4 m/s³
E
SEQ
10 PAR: 11046
Dec start jerk
1.4 m/s³
Def: 1.4
E
SEQ
10 PAR: 11046
Dec start jerk
00000001.4 m/s³
Def: 1.4
▲
1.5 m/s³
▼
1.4 m/s³
E
SEQ
11 PAR: 11048
Deceleration
0.6 m/s²
Def: 0.6
E
SEQ
11 PAR: 11048
Deceleration
00000000.6 m/s²
Def: 0.6
▲
0.7 m/s²
▼
0.5 m/s²
E
SEQ
12 PAR: 11050
Dec nal jerk
0.5 m/s³
Def: 0.5
E
SEQ
12 PAR: 11050
Dec nal jerk
00000000.5 m/s³
Def: 0.5
▲
0.6 m/s³
▼
0.4 m/s³
E
SEQ
13 PAR: 11052
Stop decel
0.7 m/s²
Def: 0.7
E
SEQ
13 PAR: 11052
Stop decel
00000000.7 m/s²
Def: 0.7
▲
0.8 m/s²
▼
0.6 m/s³
E
● Set the distance values
SEQ
14 PAR: 11104
Dist multilevel 1
0 m
Def: 0
E
SEQ
14 PAR: 11104
Dist multilevel 1
000000000 m
Def: 0
▲
1 m
▼
0 m
E
SEQ
15 PAR: 11162
Calc spd reg gains
Disabled
E
SEQ
15 PAR: 11162
Calc spd reg gains
Disabled
▲
Enabled
▼
Enabled
E
Next proceed to step 9 to save the system parameters that have been entered and those calculated by the drive using
the autotune and automatic phasing procedures.
Step - Save parameters
To save the new parameter settings, so that they are maintained also after power-off, proceed as follows:
03 STARTUP WIZARD
Save parameters?
E=Yes Down=Next
E
SEQ
01 PAR: 550
Save parameters?
Press E to exe
c
ute
E
SEQ
01 PAR: 550
Save parameters?
Do
n
e
03 STARTUP WIZARD
End of se
q
uence
Up=Back Down=Exit
(1) (2) (3) (4)
(1) Press the E key to start the save parameters procedure.
(2) Press "E" to conrm
(3) End of procedure
(4) When the parameters have been saved correctly the drive displays this screen to show that the startup wizard is
complete.
