ADL300 • Quick installation guide - Specifications and connection 41
7.2 Regulation section
Figure 7.2.1-A: Identication of cards and terminals (ADL300A)
EXP-I/O-... card EXP-DE-... card
EXP-SE-... card
EXP-EN-... card
EXP-HIP-... card
R-ADL300A card
RC-ADL300A card
CAN
(RC-ADL300A only)
PC
(RS232)
Keypad
(RS485/422)
XO
XE
XC
XS2
XS1
T3 T2 T1 XER
XE
SAFETY
Figure 7.2.1-B: Identication of cards and terminals (ADL300B)
(1) XC = CAN interface available in -C versions only.
(2) XER = Encoder Repetition available in -AD1, -ER, -ED, -ER, -E24R versions.
CAN
(RC-ADL300B-.. only)
PC
(RS232)
Keypad
(RS485/422)
XC (1)
XS2
XS1
T3 T1 XE
SAFETY
XER (2)
Figure 7.2.1-C: Identication of cards and terminals (ADL300B-...-AD1)
SAFETY
R-ADL300-AD card
PC
(RS232)
Keypad
(RS485/422)
XS2
XS1
XET5 T2
S4 S3
XERT4
