ADL300 • Quick installation guide - Specifications and connection 35
7.1 Power section
7.1.1 Cable cross-sections
Size
ADL300-...-4,
3ph
Terminals: L1 - L2 - L3 - BR - C1 - C - D - U - V - W - EM
Maximum cable cross-section
(flexible conductor)
Recommended
stripping
Recommended
terminal
Tightening
torque (min)
(mm
2
) AWG (mm) (mm) (Nm)
1040 4 10 10 None / pin 0.7 ... 0.8
1055 4 10 10 None / pin 0.7 ... 0.8
2075 6 8 10 None / pin 0.7 ... 0.8
2110 6 8 10 None / pin 0.7 ... 0.8
3150 16 6 14 None / pin 1.7 ... 1.8
3185 16 6 14 None / pin 1.7 ... 1.8
3220 16 6 14 None / pin 1.7 ... 1.8
Terminals: L1 - L2 - L3 - BR1 - BR2 - C - D - U - V - W
4300 35 2 18 None / pin 2.4 ... 4.5
4370 35 2 18 None / pin 2.4 ... 4.5
4450 35 2 18 None / pin 2.4 ... 4.5
5550
95
(BR1/BR2=50)
4/0
(BR1/BR2=1/0)
23
(BR1/BR2=27)
None / pin
14
(BR1/BR2=10)
5750 95 4/0 23 None / pin 14
Terminal: EM
4300 6 10 10 None / pin 0.7 ... 0.8
4370 6 10 10 None / pin 0.7 ... 0.8
4450 6 10 10 None / pin 0.7 ... 0.8
5550 6 10 10 None / pin 0.7 ... 0.8
5750 6 10 10 None / pin 0.7 ... 0.8
Note! The power terminal strip is extractable on sizes 1040 ... 3220. The EM terminal strip is extractable on all mechanical sizes.
Size
ADL300-...-4,
3ph
Terminals:
on structural work
Cable cross-section
Lock screw diameter
Recommended
terminal
Tightening torque (min)
(mm
2
) AWG (mm) (mm) (Nm)
1040 ... 3220
Same as the maximum cross-section used for the
power terminal strip
M5 Eyelet - Fork 6
4300 16 6 M6 Eyelet - Fork 10
4370 16 6 M6 Eyelet - Fork 10
4450 16 6 M6 Eyelet - Fork 10
5550 50 1/0 M6 Eyelet - Fork 10
5750 50 1/0 M6 Eyelet - Fork 10
Size
ADL300-...-2T,
3ph
Terminals: L1 - L2 - L3 - BR - C1 - C - D - U - V - W - EM
Maximum cable cross-section
(flexible conductor)
Recommended
stripping
Recommended
terminal
Tightening
torque (min)
(mm
2
) AWG (mm) (mm) (Nm)
2055
6 8 10 None / pin 0.7 ... 0.8
3075
16 6 14 None / pin 1.7 ... 1.8
3110
16 6 14 None / pin 1.7 ... 1.8
Terminals: L1 - L2 - L3 - BR1 - BR2 - C - D - U - V - W
4150
35 2 18 None / pin 2.4 ... 4.5
4185
35 2 18 None / pin 2.4 ... 4.5
4220
35 2 18 None / pin 2.4 ... 4.5
5300
95
(BR1/BR2=50)
4/0
(BR1/BR2=1/0)
23
(BR1/BR2=27)
None / pin
14
(BR1/BR2=10)
5370
95 4/0 23 None / pin 14
Terminal: EM
4150
6 10 10 None / pin
0.7 ... 0.8
4185
6 10 10 None / pin
0.7 ... 0.8
4220
6 10 10 None / pin
0.7 ... 0.8
5300
6 10 10 None / pin
0.7 ... 0.8
5370
6 10 10 None / pin
0.7 ... 0.8
