ADL300 • Quick installation guide - Specifications and connection 29
5.5 EMC Filter (optional)
The ADL300-...-F-4/2T inverters are equipped with an internal EMI lter, optional external lters are reported in the table.
Size Type Code
Conducted emissions according to /
Motor cable length
Dimensions:
Width x Height x Depth (mm)
Weight
(kg)
ADL300-... , 3ph
1040 EMI-FTF-480-7 S7GHL
EN 12015 / 10 m
190 x 40 x 70 0.6
1055 EMI-FTF-480-16 S7GHO 250 x 45 x 70 0.8
2075 EMI-FTF-480-16 S7GHO 250 x 45 x 70 0.8
2110 EMI-FTF-480-30 S7GHP
EN 12015 / 10 m
250 x 50 x 85 1
3150 EMI-FTF-480-30 S7GHP 250 x 50 x 85 1
3185 EMI-FTF-480-42 S7GOA 310 x 50 x 85 1.3
3220 EMI-FTF-480-42 S7GOA 310 x 50 x 85 1.3
4300 EMI-FTF-480-42 S7GOA 310 x 50 x 85 1.3
4370 EMI FTF-480-55 S7GOB 250 x 85 x 90 1.9
4450 EMI FTF-480-75 S7GOC 270 x 80 x 135 2.6
5550 EMI FTF-480-75 S7GOC 270 x 80 x 135 2.6
5750 EMI FTF-480-100 S7GOD 270 x 90 x 150 3
ADL300-...-2T, 3ph
2055
EMI-FTF-480-30 S7GHP
EN 12015 / 10 m
250 x 50 x 85 1
3075
EMI-FTF-480-30 S7GHP 250 x 50 x 85 1
3110
EMI-FTF-480-42 S7GOA 310 x 50 x 85 1.3
4150
EMI-FTF-480-42 S7GOA 310 x 50 x 85 1.3
4185
EMI FTF-480-55 S7GOB 250 x 85 x 90 1.9
4220
EMI FTF-480-75 S7GOC 270 x 80 x 135 2.6
5300
EMI FTF-480-75 S7GOC 270 x 80 x 135 2.6
5370
EMI FTF-480-100 S7GOD 270 x 90 x 150 3
ADL300-...-2M, 1ph
1011 EMI-FN2410-230-25 S7EMI1
EN12015 / 10m
130 x 93 x 76 -
1015 EMI-FN2410-230-25 S7EMI1 130 x 93 x 76 -
2022 EMI-FN2410-230-32 S7EMI2 130 x 93 x 76 -
2030 EMI-FN2410-230-32 S7EMI2
EN 12015 / 10 m
130 x 93 x 76 -
3040 EMI-FN2410-230-45 S7EMI3 130 x 93 x 76 -
3055 EMI-FN2410-230-60 S7EMI4 130 x 93 x 76 -

gefran SIEIDrive ADL300 Specifications

General

Brand	gefran
Model	SIEIDrive ADL300
Category	Inverter
Language	English
