ADL300 • Quick installation guide - Specifications and connection 25
5 - Options
5.1 Optional external fuses
5.1.1 Network side fuses (F1)
The inverter must be fused upstream on the network side.
Use fast-acting fuses only.
Size
F1 - External network side fuses
DC link capacitor hours of
service life [h]
EUROPE AMERICA
Type Code Type Code
ADL300-...-4, 3ph
1040 > 15000 GRD2/20 F4D15 A70P20 S7G48
1055 > 15000 GRD2/25 F4D16 A70P25 S7G51
2075 > 15000 GRD3/35 F4D20 A70P40 S7G52
2110 > 15000 Z22GR40 F4M16 A70P40 S7G52
3150 > 15000 Z22GR63 F4M17 A70P60-4 S7I34
3185 > 15000 Z22GR80 F4M19 A70P80 S7G54
3220 > 15000 Z22GR80 F4M19 A70P80 S7G54
4300 > 15000 Z22GR80 F4M19 A70P80 S7G54
4370 > 15000 Z22GR100 F4M21 A70P100 S849B
4450 > 15000 Z22GR100 F4M21 A70P100 S849B
5550 > 15000 S00/üf1/80/200A/690V F4G23 A70P200 S7G58
5750 > 15000 S00/üf1/80/200A/690V F4G23 A70P200 S7G58
ADL300-...-2T, 3ph
2055 > 15000 GRD2/25 F4D16 A70P25 S7G51
3075 > 15000 GRD3/35 F4D20 A70P40 S7G52
3110 > 15000 Z22GR40 F4M16 A70P40 S7G52
4150 > 15000 Z22GR63 F4M17 A70P60-4 S7I34
4185 > 15000 Z22GR80 F4M19 A70P80 S7G54
4220 > 15000 Z22GR80 F4M19 A70P80 S7G54
5300 > 15000 Z22GR80 F4M19 A70P80 S7G54
5370 > 15000 Z22GR100 F4M21 A70P100 S849B
ADL300-...-2M, 1ph
1011
> 15000 GRD2/25 F4D16 A70P25 S7G51
1015
> 15000 GRD2/25 F4D16 A70P25 S7G51
2022
> 15000 GRD3/35 F4D20 A70P40 S7G52
2030
> 15000 Z22GR40 F4M16 A70P40 S7G52
3040
> 15000 Z22GR63 F4M17 A70P60-4 S7I34
3055
> 15000 Z22GR80 F4M19 A70P80 S7G54
Technical data for fuses, including dimensions, weights, power leakage, fuse carriers etc. are reported in the corresponding manufacturers' data sheets:
GRD... (E27), S00... Jean Müller, Eltville
A70... Ferraz
