ADL300 • Quick installation guide - Specifications and connection 27
5.3 AC output chokes
The ADL300 inverter can be used with standard motors or motors designed specically for use with inverters.
The latter usually have a higher isolation rating to better withstand PWM voltage Examples of reference regulations
are provided below: motors designed for use with inverters do not require any specic ltering of output from the
inverter. For standard motors, especially with long cable runs (typically over 100 m) an output choke may be necessary
to maintain the voltage waveform with the specied limits.
The range of recommended chokes are listed in the following table. The rated current of the chokes should be approx.
20% higher than that of the inverter in order to take into account additional losses due to modulation of the output
waveform.
Size Model Code
Dimensions:
Width x Height x Depth
mm [inches]
Weight
kg [lbs]
ADL300-...-4, 3ph
1040 LU3-005 S7FG3 180 x 170 x 110 [7.1 x 6.7 x 4.3] 5.8 [12.8]
1055 LU3-005 S7FG3 180 x 170 x 110 [7.1 x 6.7 x 4.3] 5.8 [12.8]
2075 LU3-005 S7FG3 180 x 170 x 110 [7.1 x 6.7 x 4.3] 5.8 [12.8]
2110 LU3-011 S7FG4 180 x 180 x 130 [7.1 x 7.1 x 5.1] 8 [17.6]
3150 LU3-015 S7FH2 180 x 160 x 170 [7.1 x 6.3 x 6.7] 7.5 [16.5]
3185 LU3-015 S7FH2 180 x 160 x 170 [7.1 x 6.3 x 6.7] 7.5 [16.5]
3220 LU3-022 S7FH3 180 x 160 x 185 [7.1 x 6.3 x 7.3] 8 [17.6]
4300 LU3-030 S7FH4 180 x 170 x 185 [7.1 x 6.7 x 7.3] 10 [22]
4370 LU3-030 S7FH4 180 x 170 x 185 [7.1 x 6.7 x 7.3] 10 [22]
4450 LU3-037 S7FH5 180 x 170 x 185 [7.1 x 6.7 x 7.3] 10 [22]
5550 LU3-055 S7FH6 240 x 170 x 216 [9.4 x 6.7 x 8.5] 16 [35.3]
5750 LU3-090 S7FI0 180 x 195 x 165 [7.1 x 7.7 x 4.5] 15 [33.1]
ADL300-...-2T, 3ph
2055 LU3-011 S7FG4 180 x 180 x 130 [7.1 x 7.1 x 5.1] 8 [17.6]
3075 LU3-011 S7FG4 180 x 180 x 130 [7.1 x 7.1 x 5.1] 8 [17.6]
3110 LU3-015 S7FH2 180 x 160 x 170 [7.1 x 6.3 x 6.7] 7.5 [16.5]
4150 LU3-022 S7FH3 180 x 160 x 185 [7.1 x 6.3 x 7.3] 8 [17.6]
4185 LU3-030 S7FH4 180 x 170 x 185 [7.1 x 6.7 x 7.3] 10 [22]
4220 LU3-037 S7FH5 180 x 170 x 185 [7.1 x 6.7 x 7.3] 10 [22]
5300 LU3-055 S7FH6 240 x 170 x 216 [9.4 x 6.7 x 8.5] 16 [35.3]
5370 LU3-055 S7FH6 240 x 170 x 216 [9.4 x 6.7 x 8.5] 16 [35.3]
ADL300-...-2M, 1ph
1011
For information please contact the Gefran Sales Office.
1015
2022
2030
3040
3055
Note! With the inverter operated at the rated current and a frequency of 50 Hz, the output chokes cause a voltage drop of approx. 2% of the output voltage.
