ADL300 • Quick installation guide - Specifications and connection 71
• Modifying Enum values
When you press Enter on an Enum value, the rst digit on the right ashes.
Use the arrow keys to scroll all the enum values of that parameter cyclically.
Press Enter again to accept the value.
Press Prg to reject the value and restore the previous value.
E.g.:
Synchronous list, Menu 5.3 – LIFT SEQUENCES, PAR 11060 Sequence start mode (default = [0] Start forward/reverse)
05.88.
Enter

(x3)
05.03.
Enter
10. 60.
Enter
00.80.
Enter
00. 00.

00. 01.
Enter
00. 81.
• Modifying Link values
When you press Enter on a Link value, the rst digit on the right ashes.
Use the arrow keys to scroll all the links in the list associated with that parameter cyclically.
Press Enter again to accept the value.
Press Prg to reject the value and restore the previous value.
E.g.:
Synchronous list, Menu 11 – DIGITAL OUTPUTS, PAR 1410 Dig output 1X src (default = [1062] Drive OK)
11. 88.
Enter
14. 10.
Enter
10. 62.
Enter
10. 62.

10. 64.
Enter
10. 64.
• Modifying On-Off values
Boolean values are displayed with the words On and Off.
When you press Enter, the rst digit on the right ashes.
Use the up and down arrow keys to change the value cyclically from On to Off.
Press Enter again to accept the value.
Press Prg to reject the value and restore the previous value.
E.g.:
Synchronous list, Menu 5.5 – DISTANCE, PAR 11138 Out oor function (default = [0] OFF)
05.88.
Enter

(x4)
05.05.
Enter (x11)
11. 38
Enter
8o. FF.
Enter
8o. FF.

88.on.
8.2.4 Error messages when modifying a parameter
When accepting a value, if you hold Enter down or press Enter on the last digit, an error message may be displayed:
RO Read only parameter, if Enter is pressed on a read only parameter
ORNG Value outside range
DRVE Drive enabled, if you are trying to modify a parameter than cannot be modied with the drive enabled
ERR Other errors
Press Prg to clear the error message.
8.2.5 Displaying and closing Messages
Note !
Some messages may be displayed on the integrated keypad at start-up or during operation. The list of messages is provided in chapter "10.3 Messages" .
Sub-codes are not shown on the integrated keypad.
Press Prg to exit a message if it does not close automatically.
