ADL300 • Quick installation guide - Specifications and connection 23
Figure 4.9.3: Size 3 dimensions
179.4 (7.06)
155.8 (6.13)
235 (9.25)
155.8 (6.13) 23.6 (0.93) 33.5 (1.32) 168 (6.61)
218.3 (8.59)
164 (6.46)
9 (0.35)374.7 (13.69)
374 (14.72)
9 (0.35)
8.34 (0.33)
11
5.3
5.5
7
5.5
168 (6.61)
11.5
16.2
401 (15.79)
456.5 (18.32)
A
B
C
(3:5)A
(3:5)B
(3:5)C
Sizes
Dimensions: Width x Height x Depth Weight
(mm) (inches) (kg) (lbs)
ADL300.- 3150/ 3185/ 3220-...-4
235 x 401 x 179.4 9.25 x 15.79 x 7.06 10.5 23.15ADL300.- 3075/3110-...-2T
ADL300.- 3040/3055-...-2M
Figure 4.9.4: Size 4 dimensions
250 (9.84)
276 (10.87)
612 (24.09)
251.5 (9.90)
267.6 (10.53)
220 (8.66)
251.5 (9.90)
19
6.5
13
249.8 (9.83)
220 (8.66)
8.75 (0.34)
594.9 (23.42)
8.4
6.5
616 (24.25)
A
(3:5)A
Sizes
Dimensions: Width x Height x Depth Weight
(mm) (inches) (kg) (lbs)
ADL300.- 4300/ 4370/ 4450-...-4
267.6 x 616 x 276 10.53 x 24.25 x 10.87 32 70.6
ADL300.- 4150/4185-...-2T
