90 ADL300 • Quick installation guide - Specifications and connection

SEQ
06 PAR: 11160
Motor inertia
0 kgm²
Def: 0
E
SEQ
06 PAR: 11160
Motor inertia
000000000 kgm²
Def: 0
▲
1 kgm²
▼
0 kgm²
E
After setting the mechanical measurements, proceed to the next step.
Step 8 - Setting application parameters
The application data can be entered at this stage.
● Set the multispeed values
03 STARTUP WIZARD
Set application par?
E=Yes Down=Next
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
▲
rpm
▼
m/s
E

SEQ
02 PAR: 11020
Multispeed 0
5 Hz
Def: 5
E
SEQ
02 PAR: 11020
Multispeed 0
000000005 Hz
Def: 5
▲
6 Hz
▼
4 Hz
E

SEQ
03 PAR: 11022
Multispeed 1
45 Hz
Def: 45
E
SEQ
03 PAR: 11022
Multispeed 1
000000045 Hz
Def: 45
▲
46 Hz
▼
44 Hz
E

SEQ
04 PAR: 11024
Multispeed 2
20 Hz
Def: 20
E
SEQ
04 PAR: 11024
Multispeed 2
000000020 Hz
Def: 20
▲
21 Hz
▼
19 Hz
E

SEQ
05 PAR: 11026
Multispeed 3
0 Hz
Def: 0
E
SEQ
05 PAR: 11026
Multispeed 3
000000000 Hz
Def: 0
▲
1 Hz
▼
0 Hz
E

SEQ
06 PAR: 11028
Multispeed 4
0 Hz
Def: 0
E
SEQ
06 PAR: 11028
Multispeed 4
000000000 Hz
Def: 0
▲
1 Hz
▼
0 Hz
E
● Set the ramp values

SEQ
07 PAR: 11040
Acc start jerk
0.5 m/s³
Def: 0.5
E
SEQ
07 PAR: 11040
Acc start jerk
00000000.5 m/s³
Def: 0.5
▲
0.6 m/s³
▼
0.4 m/s³
E

SEQ
08 PAR: 11042
Acceleration
0.6 m/s²
Def: 0.6
E
SEQ
08 PAR: 11042
Acceleration
00000000.6 m/s²
Def: 0.6
▲
0.7 m/s²
▼
0.5 m/s²
E

SEQ
09 PAR: 11044
Acc nal jerk
1.4 m/s³
Def: 1.4
E
SEQ
09 PAR: 11044
Acc nal jerk
00000001.4 m/s³
Def: 1.4
▲
1.5 m/s³
▼
1.4 m/s³
E
