VDL200 • Quick installation guide - Specifications and connection 51
Step 9 - Save parameters
󰀨
03 STARTUP WIZARD
Save parameters?
E=Yes Down=Next
E
SEQ
01 PAR: 550
Save parameters?
Press E to exe
c
ute
E
SEQ
01 PAR: 550
Save parameters?
Do
n
e
03 STARTUP WIZARD
End of se
q
uence
Up=Back Down=Exit
(1) (2) (3) (4)
(1) Press the E key to start the save parameters procedure.
(2) Press 
(3) End of procedure
(4) When the parameters have been saved correctly the drive displays this screen to show that the startup wizard is
complete.
Final check
Note!
If you wish to use the inertia value calculated by the converter, you should copy the parameter value 5.4.20 CalcInertia (PAR 12020, Menu LIFT/ MECHANI-
CAL INFORMATION) in parameter 16.20 Inertia, PAR: 2240.
Menu 5.4 MECHANICAL DATA, parameter 5.4.20 CalcInertia, PAR: 12020, default=(S).
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT

x3
5.1 SPEED
5.2 RAMPS
5.3 LIFT SEQUENCES
5.4 MECHANICAL DATA
5.5 DISTANCE

5.4
MECHANICAL DATA
12/12 PAR: 12020
CalcInertia
4.11 kgm
2
Menu 16 SPEED REG GAINS, parameter 16.20 Inertia, PAR: 2240, default=(S).
14 MOTOR DATA
15 ENCODER CONFIG
16 SPEED REG GAINS
17 REGULATOR PARAM
18 TORQUE CONFIG

x2
16
SPEED REG GAINS
20/21 PAR: 2240
Inertia
4.11 kgm
2
Def: 4.110
Check the regulation mode setting before starting the motor and change it if necessary.
Available selections:
0 SSC control
1 Flux vector OL
2 Flux vector CL
Menu 04 DRIVE CONFIG, parameter 04.2 Regulation mode, PAR: 552, default=SSC control.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT
 
x2
04 DRIVE CONFIG
2/19 PAR: 552
Regulation mode
SSC control
Value: SSC control
