50 VDL200 • Quick installation guide - Specifications and connection
 Set the ramp values

SEQ
07 PAR: 11040
Acc start jerk
0.5 m/s³
Def: 0.5
E
SEQ
07 PAR: 11040
Acc start jerk
00000000.55 m/s³
Def: 0.5

0.6 m/s³

0.4 m/s³
E

SEQ
08 PAR: 11042
Acceleration
0.6 m/s²
Def: 0.6
E
SEQ
08 PAR: 11042
Acceleration
00000000.66 m/s²
Def: 0.6

0.7 m/s²

0.5 m/s²
E

SEQ
09 PAR: 11044
Acc nal jerk
1.4 m/s³
Def: 1.4
E
SEQ
09 PAR: 11044
Acc nal jerk
00000001.44 m/s³
Def: 1.4

1.5 m/s³

1.4 m/s³
E

SEQ
10 PAR: 11046
Dec start jerk
1.4 m/s³
Def: 1.4
E
SEQ
10 PAR: 11046
Dec start jerk
00000001.44 m/s³
Def: 1.4

1.5 m/s³

1.4 m/s³
E

SEQ
11 PAR: 11048
Deceleration
0.6 m/s²
Def: 0.6
E
SEQ
11 PAR: 11048
Deceleration
00000000.66 m/s²
Def: 0.6

0.7 m/s²

0.5 m/s²
E

SEQ
12 PAR: 11050
Dec nal jerk
0.5 m/s³
Def: 0.5
E
SEQ
12 PAR: 11050
Dec nal jerk
00000000.55 m/s³
Def: 0.5

0.6 m/s³

0.4 m/s³
E

SEQ
13 PAR: 11052
Stop decel
0.7 m/s²
Def: 0.7
E
SEQ
13 PAR: 11052
Stop decel
00000000.77 m/s²
Def: 0.7

0.8 m/s²

0.6 m/s³
E
 Set the distance values

SEQ
14 PAR: 11104
Dist multilevel 1
0 m
Def: 0
E
SEQ
14 PAR: 11104
Dist multilevel 1
0000000000 m
Def: 0

1 m

0 m
E

SEQ
15 PAR: 11162
Calc spd reg gains
Disabled
E
SEQ
15 PAR: 11162
Calc spd reg gains
Disabled

Enabled

Enabled
E
Next proceed to step 9 to save the system parameters that have been entered and those calculated by the drive using
the autotune and automatic phasing procedures.
