VDL200 • Quick installation guide - Specifications and connection 49
SEQ
06 PAR: 11160
Motor inertia
0 kgm²
Def: 0
E
SEQ
06 PAR: 11160
Motor inertia
0000000000 kgm²
Def: 0
1 kgm²
0 kgm²
E
After setting the mechanical measurements, proceed to the next step.
Step 8 - Setting application parameters
The application data can be entered at this stage.
Set the multispeed values
03 STARTUP WIZARD
Set application par?
E=Yes Down=Next
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
rpm
m/s
E
SEQ
02 PAR: 11020
Multispeed 0
5 Hz
Def: 5
E
SEQ
02 PAR: 11020
Multispeed 0
0000000055 Hz
Def: 5
6 Hz
4 Hz
E
SEQ
03 PAR: 11022
Multispeed 1
45 Hz
Def: 45
E
SEQ
03 PAR: 11022
Multispeed 1
0000000455 Hz
Def: 45
46 Hz
44 Hz
E
SEQ
04 PAR: 11024
Multispeed 2
20 Hz
Def: 20
E
SEQ
04 PAR: 11024
Multispeed 2
0000000200 Hz
Def: 20
21 Hz
19 Hz
E
SEQ
05 PAR: 11026
Multispeed 3
0 Hz
Def: 0
E
SEQ
05 PAR: 11026
Multispeed 3
0000000000 Hz
Def: 0
1 Hz
0 Hz
E
SEQ
06 PAR: 11028
Multispeed 4
0 Hz
Def: 0
E
SEQ
06 PAR: 11028
Multispeed 4
0000000000 Hz
Def: 0
1 Hz
0 Hz
E
Multi speed selection

6) commands, is possible to select Multi speed desired, according to next table:
MtlSpd S2 MtlSpd S1 MtlSpd S0 ACTIVE SPEED
0 0 0 Multispeed 0, PAR 11020
0 0 1 Multispeed 1, PAR 11022
0 1 0 Multispeed 2, PAR 11024
0 1 1 Multispeed 3, PAR 11026
1 0 0 Multispeed 4, PAR 11028
1 0 1 Multispeed 5, PAR 11030
1 1 0 Multispeed 6, PAR 11032
1 1 1 Multispeed 7, PAR 11034
