WARNING
NEVER push the controls into the “float”
position with the bucket or attachment loaded
or raised, because it will cause the lift arm to
lower rapidly.
Dumping the Load Into a Box
Carry the loaded bucket low and approach the truck,
trailer or spreader box squarely with the side of the box.
Stop your approach as close to the side of the box as
possible while allowing for clearance to raise the lift
arm and loaded bucket. Next, raise the lift arm until the
bucket clears the top of the box and move the loader
ahead to position the bucket over the inside of the box.
After the material is dumped, back away from the box
and lower the lift arm while rolling the bucket back.
Dumping the Load Over
A Solid Embankment
WARNING
Do NOT drive too close to an excavation or
ditch; BE SURE the surrounding ground has
adequate strength to support the weight of the
loader and the load.
Carry the loaded bucket as low as possible while
traveling to the dumping area. Stop the loader where the
bucket extends half-way over the edge of the
embankment. Roll the bucket forward and raise the lift
arm to dump the material. After the material is dumped,
back away from the embankment while lowering the lift
arm and rolling the bucket back.
Scraping with a Bucket
For scraping, the loader should be operated in the
forward direction. Position the lift arm down against the
loader frame. Tip the bucket cutting edge at a slight
angle to the surface being scraped. While traveling
slowly forward with the bucket in this position, material
can flow over the cutting edge and collect inside the
bucket.
907808/CP0300 44 PRINTED IN USA
Fig. 6-11: Carrying the Load
Fig. 6-12: Positioning a Bucket for Scraping
Fig. 6-13: Scraping with a Bucket
