CHAPTER 10
SERVICE
General Information
WARNING
BEFORE servicing the machine, unless
expressly instructed to the contrary, exercise
the MANDATORY SAFETY SHUTDOWN
PROCEDURE (page 10). After service has been
performed, BE SURE to restore all guards,
shields and covers to their original positions
BEFORE resuming loader operation.
NOTE:All service routines, except those
described under the “Dealer Services” topic are
owner-operator responsibilities. Refer to the
Lubrication chapter of this manual for lubrication
information.
IMPORTANT: More frequent service than the
recommended intervals may be required under
extreme operating conditions . You must decide if
your operation requires more service.
This Service chapter details procedures for performing
routine maintenance checks, adjustments and
replacements. The majority of the procedures are
referred to in the Troubleshooting and Maintenance
chapters of this manual. Refer to the separate engine
manual provided for engine-related adjustments and
servicing procedures.
IMPORTANT: ALWAYS dispose of waste
lubricating oils and hydraulic fluids according to
local regulations or take to a recycling center for
disposal; DO NOT pour onto the ground or down
the drain.
Replacement Parts
Part numbers may change. Your Gehl dealer will have
the latest part number.
Dealer Services
The following areas of internal components service,
replacement and operating adjustments require special
tools and knowledge for servicing and should be
performed only by your authorized Gehl skid loader
dealer.
Hydrostatic Components
The hydrostatic pumps are coupled directly to each
other (in tandem) and to the engine crankshaft.
Hydraulic System Gear Pump
The hydraulic system gear pump is coupled directly to
the tandem hydrostatic pump.
Hydrostatic/hydraulic system schematics can be found
in this chapter and used as a guide by the dealer for
troubleshooting and as a service parts reference.
Valves
The valves consist of control valves and system valves.
Cylinders
The hydraulic cylinders used on the loader are designed
with provisions unique to the loader application
requirements.
Electrical Components
Electrical system diagrams can be found in this chapter
and used as a guide by the dealer for troubleshooting and
service parts reference.
PRINTED IN USA 61 907808/CP0300
Part Description Gehl Part No.
Air Cleaner Element, Outer
L99453
Air Cleaner Element, Inner
L99967
Hydraulic Oil Filter Element, Spin-On
074830
Engine Oil Filter Element, Spin-On
132023
Fuel Filter Cartridge, Spin-On
132024
